5LZF1500 Marine Gearbox

Description: HCAM500 marine gearbox possesses functions of speed reduction, ahead and astern, clutching and de-clutching, and bearing propeller thrust. Down angle of the output shaft is 10°. In order to meet working conditions of high-speed ships, the product has innovations on design of volume and weight, applying aluminum alloyed housing, key components of quality alloy material and strictly selected matching components. It can match high-speed engine to form strong ship power unit.

Main Data:

nput speed	750r/min
Reduction ratio	2.88（Fast motor）	Trans. capacity	0.481kw/r/min
	2.26（Slow motor）		0.373 kw/r/min
	3.3（Vane pump）		1.6 kw/r/min
Control way	Push-and-pull flexible shaft, electrically
Center distance	462.6mm（Vane pump output）300.7mm（motor output）
L×W×H	1372×1378×1180mm
Net weight	1600kg
Bell housing	NO
